Introduction：Accuracy of ± 0.5%, ± 1%, ± 5%.
The electron beam welding process, plug-in structure, and pure copper electrode are ideal solutions for current detection applications.
Alloy materials: Manganese Copper (M), Kama (K), Iron Chromium Aluminum (F).
Working temperature range: -55 ° C~+175 ° C
Good product consistency, reliability, high stability, and strong pulse resistance.
Extremely low thermoelectric potential (<1 uV/° C)
Parasitic inductance (<3nH), fast response speed, can be used for detecting high-frequency AC currents.
Compliant with AEC-Q200.
Compliant with environmental requirements such as RoHS.
Support customization of special specifications.
