Introduction：Accuracy of ± 0.5%, ± 1%, ± 5%.
The electron beam welding process, using pure copper electrodes, is an ideal solution for current detection applications.
Alloy materials: Manganese Copper (M), Kama (K), Iron Chromium Aluminum (F).
Working temperature range: -55 ° C~+175 ° C
Good product consistency, fast heat dissipation, high stability, and strong pulse resistance.
Extremely low thermoelectric potential (<1 uV/° C)
Ultra low parasitic inductance (<3nH), fast response speed, can be used for detecting high-frequency AC currents.
Compliant with AEC-Q200.
Compliant with environmental requirements such as RoHS.
Support customization of special specifications.
