YJER2817 series four terminal shunt surface mount resistor
Model：YJER2817 series
Introduction：Accuracy is ± 1% and ± 5%.
The electron beam welding process, four terminal structure, and pure copper electrode are ideal solutions for current detection applications.
Alloy Material: Manganese Copper (M)
Working temperature range: -55 ° C~+175 ° C
Good product consistency, reliability, high stability, and strong pulse resistance.
Extremely low thermoelectric potential (<1 uV/° C)
Ultra low parasitic inductance (<3nH), fast response speed, can be used for detecting high-frequency AC currents.
Compliant with AEC-Q200.
Compliant with environmental requirements such as RoHS.
Support customization of special specifications.
